GE-SW

klzné ložiská s kosouhlým stykom, styčná plocha tvrdý chróm/PTFE, bezúdržbové

na použitie pri jednosmerných, dynamických radiálnych a axiálnych zaťaženiach

vonkajší krúžok:
ložisková oceľ 100Cr6, AISI 52100, tvrdená, s PTFE vložkou

vnútorný krúžok:
ložisková oceľ 100Cr6, AISI 52100, tvrdená, leštená, tvrdý chróm

Na vyžiadanie vo vyhotovaní z nehrdzavejúcej ocele

CAD DATA

Size (D)BMATSr1, r1s mindKStatic radial load C0 kNDynamic radial load C kNPivoting angle α (o)Weight (g)
25 0
-0.012
151447 0
-0.014
15 +0.25
-0.40
0.6142225892.5148
28 0
-0.012
151552 0
-0.016
16 +0.25
-0.40
11472701002186
30 0
-0.012
171555 0
-0.016
17 +0.25
-0.40
1.3149.52851104.5208
32 0
-0.012
171658 0
-0.016
17 +0.25
-0.40
21523201252241
35 0
-0.012
181662 0
-0.016
18 +0.25
-0.40
2.1155.53401354268
40 0
-0.012
191768 0
-0.016
19 +0.25
-0.40
2.81624001603.5327
45 0
-0.012
201875 0
-0.016
20 +0.25
-0.40
3.5168.54701903416
50 0
-0.012
201980 0
-0.016
20 +0.25
-0.40
4.31745402151.5455
55 0
-0.015
232090 0
-0.018
23 +0.25
-0.50
51.1826302504645
60 0
-0.015
232195 0
-0.018
23 +0.25
-0.50
5.71.188.57102852.5714
65 0
-0.015
2322100 0
-0.018
23 +0.25
-0.50
6.51.193.57903151759
70 0
-0.015
2523110 0
-0.018
25 +0.25
-0.50
7.21.110290036021040
75 0
-0.015
2524115 0
-0.018
25 +0.25
-0.50
7.91.110798039511120
80 0
-0.015
2925.5125 0
-0.020
29 +0.25
-0.50
8.61.111511204503.51540
85 0
-0.015
2926.5130 0
-0.020
29 +0.25
-0.60
9.41.1122124049521610
90 0
-0.020
3228140 0
-0.020
32 +0.25
-0.60
10.11.5128.513805503.52090
95 0
-0.020
3229.5145 0
-0.020
32 +0.25
-0.60
10.81.5135153061022220
100 0
-0.020
3231150 0
-0.020
32 +0.25
-0.60
11.61.514116806700.52340
105 0
-0.020
3532.5160 0
-0.020
35 +0.25
-0.60
12.32148185074022930
110 0
-0.020
3834170 0
-0.020
38 +0.25
-0.60
132155202081033680
120 0
-0.020
3837180 0
-0.025
38 +0.25
-0.60
14.5216823909550.53970
130 0
-0.020
4543200 0
-0.025
45 +0.35
-0.70
182.51883110124015920
140 0
-0.020
4543210 0
-0.025
45 +0.35
-0.70
192.51983270131016330
150 0
-0.025
4846225 0
-0.030
48 +0.35
-0.70
2032113730149018010
160 0
-0.025
5149240 0
-0.030
51 +0.35
-0.70
2032254240169019790
170 0
-0.025
5755260 0
-0.035
57 +0.35
-0.70
21324652002080112300
180 0
-0.025
6461280 0
-0.035
64 +0.35
-0.70
21326061002440117400
190 0
-0.030
6462290 0
-0.035
64 +0.35
-0.80
263275656026200.518200
200 0
-0.030
7066310 0
-0.035
70 +0.35
-0.80
263290736029401.523800
